Compare products
The right tool for every job
Our marking devices differ in their printing range, range of functions and focus of use. The comparison helps you to quickly find the right device for your application - clearly laid out, easy to understand and at a glance.
All REINER® marking devices are designed for direct printing without labels. The differences lie in the print area, data transfer, ease of use, and expansion options.
Printed content
Text, numbers, date, time, 1D/2D barcodes consecutively, graphics
Text, numbers, date, time, 1D/2D barcodes consecutively, graphics
Text, numbers, date, time, 1D/2D barcodes, graphics
Text, numbers, date, time
Text, numbers, date, time
Text, numbers, date, time, 1D & 2D codes, QR codes, Data Matrix, graphics
Printing area (WxH)
85 mm × 26 mm (1 inch), multi-line
85 mm × 26 mm (1 inch), multi-line
65 mm × 12.7 mm, multiple lines
42 mm × 3.2 mm per line 2 lines, 20 characters each
single line, max. 40 characters
26 x 85 mm
Printing area (WxH) with accessories
85 mm × 52 mm (2 inches)
85 mm × 52 mm (2 inches)
–
–
–
–
speed
< 0.9 s/impression
< 0.9 s/impression
< 0.9 s/impression
approx. 1 s/print
Approx. 1.5 s/impression
Up to 500 mm/s (30 m/min)
print resolution
300 dpi
300 dpi
300 dpi
96 dpi
96 dpi
300 dots per inch
Device dimensions (LxWxH)
195 × 100 × 200 mm
195 × 100 × 200 mm
5.4 × 3.3 × 6.3 inches
4 × 3 × 6 in
175 × 30 × 45 mm
210 × 62 × 92 mm
Weight
approx. 900 g
approx. 900 g
approx. 520 g
approx. 500 g
approx. 125 g
about 1,000 g
technology
display
Yes
Yes
–
Yes
–
Yes
Operation
Buttons, release button (3 pcs.)
Buttons, release button (3 pcs.)
Rotary wheel, release button
Buttons, release button
release button
Display with buttons
battery
4x AA NiMH rechargeable batteries
4x AA NiMH rechargeable batteries
3x AA NiMH rechargeable batteries
2x AA NiMH rechargeable batteries
2x AA NiMH rechargeable batteries
24 VDC / 3A (Class III)
Battery capacity
approx. 1,000 prints
approx. 1,000 prints
approx. 1,000 prints
approx. 2,000 prints
approx. 1,000 prints
Infinite thanks to the power supply
printing technology
Thermal inkjet (TIJ)
Thermal inkjet (TIJ)
Thermal inkjet (TIJ)
Thermal inkjet (TIJ)
Thermal inkjet (TIJ)
Thermal inkjet (TIJ)
data transmission
USB, Bluetooth, Wi-Fi
USB, Bluetooth, Wi-Fi
USB, Bluetooth
USB, Bluetooth
USB
USB, microSD, Wi-Fi
Sensor interface
Yes
–
–
–
–
Photosensor, Encoder, Sensor Interface
External triggering possible
Yes
Yes
Yes
Yes
–
Yes
Inks & Paints
colors
Certificates & Standards
CE, RoHS, INGEDE-11, EPAL-QR pallet standard etc.
CE, RoHS, INGEDE-11, EPAL pallet standard etc.
CE, RoHS etc.
CE, RoHS etc.
CE etc.
CE, GS1, FC, UKCA
Materials & Applications
Suitable materials
Paper, cardboard, wood, plastics (PE, PP, PET), metal, glass, textiles
Paper, cardboard, wood, plastics (PE, PP, PET), metal, glass, textiles
Paper, cardboard, wood, plastics (PE, PP, PET), metal, glass, textiles
Paper, cardboard, wood, plastics (PE, PP, PET), metal, glass, textiles, eggshells
Paper, cardboard
Paper, cardboard, wood, plastic (PE, PP, PET), metal, glass, textiles
Typical applications
Wood labeling (IPPC), documents, packaging (food, hygiene products, cosmetics, etc.), product labeling, best-before date + batch labeling, industrial parts repackaging, barcodes (reading, copying, printing), incoming mail
Wood labeling (IPPC), documents, packaging (food, hygiene products, cosmetics, etc.), product labeling, best-before date + batch labeling Industrial parts Incoming mail
Documents, packaging (food, hygiene products, cosmetics, etc.), best-before date + batch labeling
Documents, packaging (food, hygiene products, cosmetics, etc.), cosmetic packaging, beverage cans, bottles, best-before date + batch labeling
Documents, forms
Wood marking (IPPC), packaging materials (food, hygiene products, cosmetics, etc.), product labeling, best-by dates and lot numbers on industrial parts, repackaging of beverage cans and bottles
Printed content
Text, numbers, date, time, 1D/2D barcodes consecutively, graphics
Printing area (WxH)
85 mm × 26 mm (1 inch), multi-line
Printing area (WxH) with accessories
85 mm × 52 mm (2 inches)
speed
< 0.9 s/impression
print resolution
300 dpi
Device dimensions (LxWxH)
195 × 100 × 200 mm
Weight
approx. 900 g
display
Yes
Operation
Buttons, release button (3 pcs.)
battery
4x AA NiMH rechargeable batteries
Battery capacity
approx. 1,000 prints
printing technology
Thermal inkjet (TIJ)
data transmission
USB, Bluetooth, Wi-Fi
Sensor interface
Yes
External triggering possible
Yes
colors
black, yellow
Certificates & Standards
CE, RoHS, INGEDE-11, EPAL-QR pallet standard etc.
Printed content
Text, numbers, date, time, 1D/2D barcodes consecutively, graphics
Printing area (WxH)
85 mm × 26 mm (1 inch), multi-line
Printing area (WxH) with accessories
85 mm × 52 mm (2 inches)
speed
< 0.9 s/impression
print resolution
300 dpi
Device dimensions (LxWxH)
195 × 100 × 200 mm
Weight
approx. 900 g
display
Yes
Operation
Buttons, release button (3 pcs.)
battery
4x AA NiMH rechargeable batteries
Battery capacity
approx. 1,000 prints
printing technology
Thermal inkjet (TIJ)
data transmission
USB, Bluetooth, Wi-Fi
Sensor interface
–
External triggering possible
Yes
colors
black, yellow
Certificates & Standards
CE, RoHS, INGEDE-11, EPAL pallet standard etc.
Printed content
Text, numbers, date, time, 1D/2D barcodes, graphics
Printing area (WxH)
65 mm × 12.7 mm, multiple lines
Printing area (WxH) with accessories
–
speed
< 0.9 s/impression
print resolution
300 dpi
Device dimensions (LxWxH)
5.4 × 3.3 × 6.3 inches
Weight
approx. 520 g
display
–
Operation
Rotary wheel, release button
battery
3x AA NiMH rechargeable batteries
Battery capacity
approx. 1,000 prints
printing technology
Thermal inkjet (TIJ)
data transmission
USB, Bluetooth
Sensor interface
–
External triggering possible
Yes
colors
black
Certificates & Standards
CE, RoHS etc.
Printed content
Text, numbers, date, time
Printing area (WxH)
42 mm × 3.2 mm per line 2 lines, 20 characters each
Printing area (WxH) with accessories
–
speed
approx. 1 s/print
print resolution
96 dpi
Device dimensions (LxWxH)
4 × 3 × 6 in
Weight
approx. 500 g
display
Yes
Operation
Buttons, release button
battery
2x AA NiMH rechargeable batteries
Battery capacity
approx. 2,000 prints
printing technology
Thermal inkjet (TIJ)
data transmission
USB, Bluetooth
Sensor interface
–
External triggering possible
Yes
colors
black, yellow, magenta, eggplant
Certificates & Standards
CE, RoHS etc.
Printed content
Text, numbers, date, time
Printing area (WxH)
single line, max. 40 characters
Printing area (WxH) with accessories
–
speed
Approx. 1.5 s/impression
print resolution
96 dpi
Device dimensions (LxWxH)
175 × 30 × 45 mm
Weight
approx. 125 g
display
–
Operation
release button
battery
2x AA NiMH rechargeable batteries
Battery capacity
approx. 1,000 prints
printing technology
Thermal inkjet (TIJ)
data transmission
USB
Sensor interface
–
External triggering possible
–
colors
black
Certificates & Standards
CE etc.
Printed content
Text, numbers, date, time, 1D & 2D codes, QR codes, Data Matrix, graphics
Printing area (WxH)
26 x 85 mm
Printing area (WxH) with accessories
–
speed
Up to 500 mm/s (30 m/min)
print resolution
300 dots per inch
Device dimensions (LxWxH)
210 × 62 × 92 mm
Weight
about 1,000 g
display
Yes
Operation
Display with buttons
battery
24 VDC / 3A (Class III)
Battery capacity
Infinite thanks to the power supply
printing technology
Thermal inkjet (TIJ)
data transmission
USB, microSD, Wi-Fi
Sensor interface
Photosensor, Encoder, Sensor Interface
External triggering possible
Yes
colors
Black, Yellow
Certificates & Standards
CE, GS1, FC, UKCA
Not sure which device fits?
We will advise you free of charge.
Together, we will clarify which marking device is suitable for your application - without obligation, in a practical manner and tailored to your requirements.
